Lighter and robust
New body, maximum ergonomics
Top-range and Low consumption High-end Aluminium aircaps
There are no gaskets in couplings between air and paint
Extra deposit capacity (1L.) and application speed
With a light injected-aluminium body, it is a top level product with an excellent price/quality ratio.
High speed application.
Large size fan.
Application of enamels, varnishes, primers and basecoats.
Nozzles and needles in stainless steel.
HVLP and EPA aircaps that comply with regulations concerning solvent emissions.
Aircap EPA: Minimum air consumption with high quality application (>2HP).
|Weight with cup||925 gr|
|Dimensions||29 x 17,5 x 11 cm|
|Air inlet couplings||BSP 1/4” M|
|Design pressure||8 bar|
|Maximum recommended application distance||2 bar|
|Air consumption (2 bar inlet)||15-18 cm|
|Air consumption (2 bar inlet)||240 L/min|
|Average sound pressure level||80 dB|
|Materials in contact with the product||chromed aluminium, anodized aluminium, POM, INOX, Teflon|
|10120910||3300 GTO Suction 1.40[EPA]|
|10120911||3300 GTO Suction 1.60[EPA]|
|10120912||3300 GTO Suction 1.80[EPA]|
